Model | Units | KX-CQD-H2 |
Rated capacity | kg | 2000 |
Lifting height | mm | 3000 |
Fork length | mm | 1220 |
Fork width | mm | 600 |
Overall length | mm | 3180 |
Overall width | mm | 1055 |
Overall height | mm | 2110 |
Turning radius | mm | 1900 |
Loading wheel size | mm | Φ210x80 |
Driving wheel size | mm | Φ115x50 |
Distance between front wheel and rear wheel | mm | 1320 |
Lifting speed (unladen/ laden) | mm/s | 120/60 |
Travel speed (unladen/ laden) | Km/h | 5/4 |
Gradeability (unladen/ laden) | • | 5 |
Drive motor | Kw | 2.2 |
Lift motor | Kw | 2.2 |
Battery | V/Ah | 24/210 |
Net weight | kg | 1830 |
