Model | Units | KX-CPD15 | KX-CPD20 | KX-CPD25 | KX-CPD30 | KX-CPD35 | KX-CPD40 |
Rated capacity | Kg | 1500 | 2000 | 2500 | 3000 | 3500 | 4000 |
Lifting height | mm | 3000 | 3000 | 3000 | |||
Fork length | mm | 1220 | 1220 | 1220 | |||
Tilting angle (F/R) | ° | 6/10 | 6/10 | 6/10 | |||
Overall length | mm | 3218 | 3595 | 3730 | |||
Overall width | mm | 1080 | 1130 | 1250 | |||
Overall height | mm | 2070 | 2155 | 2200 | |||
Ground clearance | mm | 113 | 130 | 130 | |||
Turning radius | mm | 1900 | 2090 | 2410 | |||
Wheel base | mm | 1250 | 1521 | 1630 | |||
Lifting speed (unladen/ laden) | mm/s | 210 | 340 | 340 | |||
Travel speed (unladen/ laden) | Km/h | 8 | 12 | 12 | |||
Gradeability (laden) | ° | 15 | 15 | 15 | |||
Drive motor | kw | 5 | 8 | 11 | 16.5 | ||
Lift motor | kw | 6.8 | 10 | 12 | 13.5 | ||
Battery | V/Ah | 24/400 | 48/400 | 48/560 | 48/600 | 80/500 | 80/550 |
Net weight | Kg | 2330 | 2850 | 3150 | 3920 | 4760 | 5570 |
