Model | Units | KX-CPDE15 |
Rated capacity | Kg | 1500 |
Lifting height | mm | 3000 |
Fork length | mm | 1150/1220 |
Fork width | mm | 660 |
Overall length | mm | 3030 |
Overall width | mm | 933 |
Overall height | mm | 2115 |
Turning radius | mm | 1710 |
Wheel material | PU | Polyurethane |
Loading wheel size | mm | Φ210x80 |
Driving wheel size | mm | Φ250x75 |
Distance between front wheel and rear wheel | mm | 1374 |
Ground clearance | mm | 93 |
Travel speed (unladen/ laden) | km/h | 5.5/5 |
Lifting speed (unladen/ laden) | mm/s | 100/80 |
Gradeability (laden) | ° | 3 |
Tilting angle (F/R) | ° | 3/6 |
Drive motor | kw | 1.8 |
Lift motor | kw | 2.2 |
Battery | V/Ah | 2x12/150 |
Net weight | Kg | 1882 |
