Model | Units | KX-PPT |
Rated capacity | kg | 1500 |
Min. fork height | mm | 85 |
Max. fork height | mm | 200 |
Overall length | mm | 1540/1610 |
Wheelbase | mm | 1270 |
Overall width | mm | 550 |
Front wheel track | mm | 380 |
Fork size | mm | 1150(1220)x160x50 |
Overall height | mm | 1300 |
Front wheel size | mm | Φ80x70 |
Driving wheel size | mm | Φ130x55 |
Turning radius | mm | 1426 |
Drive motor | V/Kw | 24/0.45 |
Battery | V/Ah | 24/20 lithium-ion battery |
Net weight | kg | 115 |
